Relief map
Assign a level to the base, logo, border and any recessed line. Show the profile in section as well as from the front.
Elevation lab / moulded identity
3D Silicone Heat Transfer Patches
3D silicone patches give a custom logo a raised, tactile face without relying on print alone. Build the project around measurable relief, final size, garment compatibility, application evidence and a clearly coded bulk order.
Patch anatomy
Three decisions create the raised logo
A 3D raised silicone badge becomes predictable when visual depth, boundary and receiving surface are specified independently.
Outside geometry
Define the finished width, height, corner treatment and whether the edge follows the mark or a geometric field.
Application interface
Name the target garment, placement and proposed heat-transfer construction. Approve the combination after a representative trial.
Depth choreography
Make every elevation earn its place
Level 0
Base plane
Sets the complete footprint, background field and relationship to the garment color.
Level 1
Primary mark
Carries the wordmark or icon that must remain readable at true size.
Level 2
Selective accent
Adds a controlled highlight without crowding small counters or weakening nearby gaps.
Mould-to-bulk route
Move through five release gates
Vector audit
Lock exact wording, dimensions and protected proportions.
Relief proof
Approve the annotated height relationships and edge.
Loose sample
Inspect color, flexibility, surface and smallest details.
Garment trial
Record the patch, fabric, equipment and accepted method.
Bulk control
Compare production to the coded approval sample and pack list.
Database spotlight
Active patch references with live commercial fields
The following records come directly from the product database. Prices and minimums describe the recorded catalog item; custom tooling, freight and revised specifications require a current quote.
GZ-FC-009
Custom 3D Silicone Heat Transfer Logo Patches
- Material: Silicone
- Size: 6 × 8 cm
- MOQ: 100
- Recorded price: $0.45 USD
Application record
Treat press instructions as part of the approved construction
Time, temperature, pressure, protective layers, cooling and carrier removal must come from the supplier for the selected patch. Do not copy settings from a visually similar sample.
- Identify the exact patch revision and receiving garment.
- Confirm placement and access around seams, zippers and curves.
- Apply with the issued process and document the equipment.
- Inspect the face, edges, reverse and surrounding fabric.
- Retest when the garment or patch construction changes.
Evidence board
Ask for results that match the intended use
A wash-tested claim only becomes useful when the method, cycle count, garment, acceptance criteria and result are attached to the same sample identity.
AppearanceColor, gloss, relief and surface marks
BondEdge lift, movement and complete separation
GarmentShine, distortion, strike-through and damage
TraceabilitySample code, test date, method and reviewer
Technical questions
3D silicone patch FAQ
What creates the 3D effect in a silicone heat transfer patch?
A controlled relief map separates base, raised lettering, icons and borders into defined levels. The sample establishes the visible depth and detail that the finished size can support.
What is the recorded MOQ for the silicone logo patch reference?
Catalog reference GZ-FC-009 records an MOQ of 100 pieces. Confirm whether a custom order minimum applies per design, size or colorway in the current quotation.
Can raised silicone patches be used on stretch clothing?
Compatibility depends on the exact patch construction, receiving fabric, finish, stretch direction and application process. Test a representative garment and approve the result before bulk production.
Do I need a mould for a custom 3D silicone badge?
Dimensional artwork may require project-specific tooling or setup. The quotation should identify any charge, what revision it covers and whether a later artwork or size change triggers new setup.
How should I approve a heat-transfer patch sample?
Review exact artwork, true-size detail, relief, color, edge, flexibility, garment placement and the applied result. Keep the sample code and application record with the purchase specification.
Can I ask for a free sample before ordering?
Yes, open Free Samples and provide your application and destination. The team will confirm available reference samples, custom sampling options and any shipping or project conditions.
Start with the elevation map
Price the patch your garment actually needs
Send editable artwork, finished size, relief direction, colors, garment construction, placement, quantities and destination.
